Capacitance
Range Table
C5750 [EIA CC2220]
Class 2 (Temperature Stable)
Temperature Characteristics: X7R (-55 to +125ºC, ±15%), X5R (-55 to +85ºC, ±15%), Y5V(-30 to +85ºC, +22/-82%)
TDK Part Number
(Ordering Code)
Temperature
Characteristics
Rated
Voltage
Capacitance
(pF)
Capacitance
Tolerance
Thickness
(mm)
C5750X7R1H475K/2.00
C5750X7R1H475M/2.00
C5750X7R1H475M/2.80
C5750X7R1H685K
C5750X7R1H685M
C5750X7R1H106K
C5750X7R1H106M
C5750X7R1E106M
C5750X7R1E156M
C5750X7R1E226M
C5750X7R1C226M
C5750X7R1C476M
C5750X5R1H106K
C5750X5R1H106M
C5750X5R1E226M
C5750X5R1C336M
C5750X5R1C476M
C5750X5R1A686M
C5750X5R1A107M
C5750X5R0J107M
C5750Y5V1H226Z
C5750Y5V1E476Z
C5750Y5V1C107Z
C5750Y5V1A107Z
X7R
X7R
X7R
X7R
X7R
X7R
X7R
X7R
X7R
X7R
X7R
X7R
X5R
X5R
X5R
X5R
X5R
X5R
X5R
X5R
Y5V
Y5V
Y5V
Y5V
50V
50V
50V
50V
50V
50V
50V
25V
25V
25V
16V
16V
50V
50V
25V
16V
16V
10V
10V
6.3V
50V
25V
16V
10V
4,700,000
± 10%
± 20%
± 20%
± 10%
± 20%
± 10%
± 20%
± 20%
± 20%
± 20%
± 20%
± 20%
± 10%
± 20%
± 20%
± 20%
± 20%
± 20%
± 20%
± 20%
+80/-20%
+80/-20%
+80/-20%
+80/-20%
2.00 ± 0.20
2.00 ± 0.20
2.80 ± 0.20
2.50 ± 0.30
2.50 ± 0.30
2.30 ± 0.20
2.30 ± 0.20
2.00 ± 0.20
2.30 ± 0.20
2.50 ± 0.30
2.80 ± 0.20
2.30 ± 0.20
2.30 ± 0.20
2.30 ± 0.20
2.30 ± 0.20
2.00 ± 0.20
2.30 ± 0.20
2.30 ± 0.20
2.80 ± 0.20
2.80 ± 0.20
2.00 ± 0.20
2.00 ± 0.20
2.50 ± 0.30
2.50 ± 0.30
4,700,000
4,700,000
6,800,000
6,800,000
10,000,000
10,000,000
10,000,000
15,000,000
22,000,000
22,000,000
47,000,000
10,000,000
10,000,000
22,000,000
33,000,000
47,000,000
68,000,000
100,000,000
100,000,000
22,000,000
47,000,000
100,000,000
100,000,000
