Input:
Output:
35-75 V
2.5 V
Current:
Package:
15 A
Eighth-brick
Technical Specification
ELECTRICAL CHARACTERISTICS (Continued)
Parameter
Min.
Typ.
Max.
Units Notes & Conditions
ISOLATION CHARACTERISTICS
Isolation Voltage (dielectric strength)
Isolation Resistance
2000
30
V
M
Ω
Isolation Capacitance
470
pF
Higher isolation capacitance can be added externally
Buck stage and isolation stage
FEATURE CHARACTERISTICS
Switching Frequency
220
250
280
kHz
ON/OFF Control (Option P)
Off-State Voltage
-2
0.8
18
V
V
On-State Voltage
2.4
ON/OFF Control (Option N)
Off-State Voltage
2.4
-2
18
V
V
On-State Voltage
0.8
ON/OFF Control (Either Option)
Pull-Up Voltage
Figures A & B
Vin/6
40
15
V
Pull-Up Resistance
k
Ω
Output Voltage Trim Range
Output Voltage Remote Sense Range
Output Over-Voltage Protection
Over-Temperature Shutdown
Over-Temperature Shutdown Restart Hysteresis
Load Current Scale Factor
RELIABILITY CHARACTERISTICS
Calculated MTBF (Telcordia)
Calculated MTBF (MIL-217)
Field Demonstrated MTBF
-20
+10
+10
130
%
Measured across Pins 8 & 4; Figure C
Measured across Pins 8 & 4
%
%
120
125
125
10
Over full temp range; % of nominal Vout
Average PCB Temperature
°C
°C
500
See App Note: Output Load Current Calc.
o
2.4
1.4
106 Hrs. TR-NWT-000332; 80% load,300LFM, 40 C T
a
a
106 Hrs. MIL-HDBK-217F; 80% load, 300LFM, 40 C T
o
106 Hrs. See our website for details
STANDARDS COMPLIANCE
Parameter
P
Notes
STANDARDS COMPLIANCE
UL/cUL 60950
File # E194341, Basic insulation & pollution degree 2
Certified by TUV
EN60950
72/23/EEC
93/68/EEC
Needle Flame Test (IEC 695-2-2)
IEC 61000-4-2
test on entire assembly; board & plastic components UL94V-0 compliant
ESD test, 8kV - NP, 15kV air - NP (Normal Performance)
GR-1089-CORE
Section 7 - electrical safety, Section 9 - bonding/grounding
Telcordia (Bellcore) GR-513
•
An external input fuse must always be used to meet these safety requirements. Contact SynQor for official safety
certificates on new releases or download from the SynQor website.
QUALIFICATION TESTING
Parameter
P
# Units Test Conditions
QUALIFICATION TESTING
Life Test
32
95% rated Vin and load, units at derating point, 1000 hours
Vibration
5
10-55Hz sweep, 0.060” total excursion,1 min./sweep, 120 sweeps for 3 axis
100g minimum, 2 drops in x and y axis, 1 drop in z axis
-40°C to 100°C, unit temp. ramp 15°C/min., 500 cycles
Toperating = min to max, Vin = min to max, full load, 100 cycles
Tmin-10°C to Tmax+10°C, 5°C steps, Vin = min to max, 0-105% load
85°C, 85% RH, 1000 hours, 2 minutes on and 6 hours off
MIL-STD-883, method 2003
Mechanical Shock
Temperature Cycling
Power/Thermal Cycling
Design Marginality
Humidity
5
10
5
5
5
Solderability
15 pins
•
Extensive characterization testing of all SynQor products and manufacturing processes is performed to ensure that we supply
robust, reliable product. Contact factory for official product family qualification document.
OPTIONS
PATENTS
SynQor provides various options for Enable Logic and Pin Length SynQor is protected under various patents, including but not lim-
for this family of DC/DC converters. Please consult the last page ited to U.S. Patent numbers 5,999,417; 6,222,742 B1;
of this specification sheet for information on available options.
6,594,159 B2; 6,545,890 B2.
Product # PQ60025EML15
Phone 1-888-567-9596
www.synqor.com
Doc.# 005-2EM625E Rev. C
09/08/05
Page 4
