SM39A16M1
8-Bit Micro-controller
16KB with ISP Flash
& 1K+256B RAM embedded
ADC6EN = 1 - Enable ADC channel 6
ADC5EN: ADC channels 5 enable.
ADC5EN = 1 - Enable ADC channel 5
ADC4EN: ADC channels 4 enable.
ADC4EN = 1 - Enable ADC channel 4
ADC3EN: ADC channels 3 enable.
ADC3EN = 1 - Enable ADC channel 3
ADC2EN: ADC channels 2 enable.
ADC2EN = 1 - Enable ADC channel 2
ADC1EN: ADC channels 1 enable.
ADC1EN = 1 - Enable ADC channel 1
ADC0EN: ADC channels 0 enable.
ADC0EN = 1 - Enable ADC channel 0
Mnemonic: ADCC2
Address: ACh
7
Start
6
5
4
3
2
1
0
Reset
08H
Adjust
PWMTriggerEN
EXTTriggerEN
ADCMODE
ADCCH[2:0]
Start When this bit is set, the ADC will be start conversion.
(SW trigger conversion)
ADJUST Adjust the format of ADC conversion DATA.
ADJUST = 0 - (default value)
ADC data high byte ADCD [9:2] = ADCDH [7:0].
ADC data low byte ADCD [1:0] = ADCDL [1:0].
ADJUST = 1- ADC data high byte ADCD [9:8] = ADCDH [1:0].
ADC data low byte ADCD [7:0] = ADCDL [7:0].
PWMTriggerEN PWM trigger ADC to start conversion.
(HW internal trigger conversion)
0 = disable
1 = enable
EXTTriggerEN External Pin trigger ADC to start conversion.
(HW external trigger conversion)
0 = disable
1 = enable
ADCMODE 0 = continuous mode
1 = single-shot mode
Specifications subject to change without notice contact your sales representatives for the most recent information.
ISSFD-M069 Ver C SM39A16M1 7/31/2013
- 92 -
