VN5770AK-E
Electrical characteristics
Table 17. Protection and diagnostics (-40°C < T < 150°C, unless otherwise
j
specified)
Symbol
Parameter
Test Conditions
Min
Typ
Max Unit
Ilim
Drain Current Limit
VIN=5V; VDS=13V
6
8.5
12
200
20
A
Step Response
Current Limit
tdlim
VIN=5V; VDS=13V
10
µs
Overtemperature
Shutdown
Tjsh
150
175
°C
Overtemperature
Reset
Tjrs
Igf
135
10
°C
Fault Sink Current
VIN=5V; VDS=13V; Tj=Tjsh
starting Tj=25°C; VDD=24V
15
mA
Single Pulse
Eas
100
mJ
VIN=5V; Rgen=RIN MINn=220Ω;
L=24mH
Avalanche Energy
Figure 18. Static drain source on resistance
Figure 19. Derating curve
Rds(on) (mohms)
1000
Tj=-40ºC
900
Vin=2.5V
800
700
600
Tj=25ºC
500
TBD
400
300
Tj=150ºC
200
100
0
0.05 0.1 0.15 0.2 0.25 0.3 0.35 0.4 0.45 0.5 0.55
Id(A)
Figure 20. Transconductance
Figure 21. Transfer characteristics
Gfs (S)
11
Idon (A)
6
5.5
10
Vds=13.5V
Vds=13V
Tj=-40ºC
5
9
Tj=25ºC
4.5
8
Tj=150ºC
4
7
Tj=150ºC
3.5
6
5
4
3
2
1
0
3
Tj=-40ºC
2.5
2
1.5
Tj=25ºC
1
0.5
0
0
0.5
1
1.5
2
2.5
3
3.5
4
4.5
5
5.5
1.5
2
2.5
3
3.5
4
4.5
5
5.5
6
Id (A)
Vin (V)
