TDA7377
tees the highest possible power performances
with extremely reduced component count. The
on-board clip detectorsimplifies gain compression
operation. The fault diagnostics makes it possible
to detect mistakes during car radio set assembly
and wiring in the car.
DESCRIPTION
The TDA7377 is a new technology class AB car
radio amplifier able to work either in DUAL
BRIDGE or QUAD SINGLE ENDED configuration.
The exclusive fully complementary structureof the
output stage and the internally fixed gain guaran-
GENERAL STRUCTURE
ABSOLUTE MAXIMUM RATINGS
Symbol
Vop
Parameter
Value
Unit
V
Operating Supply Voltage
DC Supply Voltage
18
28
VS
V
Vpeak
IO
Peak Supply Voltage (for t = 50ms)
50
V
Output Peak Current (not repetitive t = 100 s)
4.5
A
µ
IO
Output Peak Current (repetitive f > 10Hz)
3.5
A
Ptot
Power Dissipation (Tcase = 85°C)
Storage and Junction Temperature
36
W
°C
Tstg, Tj
-40 to 150
THERMAL DATA
Symbol
Description
Value
1.8
Unit
Rth j-case
Thermal Resistance Junction-case
Max
°C/W
PIN CONNECTION (Topview)
DIAGNOSTICS
2/10
