STM32F105xx, STM32F107xx
Electrical characteristics
Input/output AC characteristics
The definition and values of input/output AC characteristics are given in Figure 17 and
Table 37, respectively.
Unless otherwise specified, the parameters given in Table 37 are derived from tests
performed under the ambient temperature and V supply voltage conditions summarized
in Table 9.
DD
(1)
Table 37. I/O AC characteristics
MODEx[1:0]
bit value(1)
Symbol
Parameter
Conditions
Min Max Unit
fmax(IO)out Maximum frequency(2) CL = 50 pF, VDD = 2 V to 3.6 V
2
MHz
ns
Output high to low
tf(IO)out
125(3)
10
level fall time
CL = 50 pF, VDD = 2 V to 3.6 V
Output low to high
tr(IO)out
125(3)
10
level rise time
fmax(IO)out Maximum frequency(2) CL = 50 pF, VDD = 2 V to 3.6 V
MHz
ns
Output high to low
tf(IO)out
25(3)
01
level fall time
CL = 50 pF, VDD = 2 V to 3.6 V
Output low to high
tr(IO)out
25(3)
level rise time
CL = 30 pF, VDD = 2.7 V to 3.6 V
Fmax(IO)out Maximum frequency(2) CL = 50 pF, VDD = 2.7 V to 3.6 V
CL = 50 pF, VDD = 2 V to 2.7 V
50
30
MHz
MHz
MHz
20
CL = 30 pF, VDD = 2.7 V to 3.6 V
Output high to low
level fall time
5(3)
8(3)
12(3)
5(3)
8(3)
12(3)
11
tf(IO)out
tr(IO)out
tEXTIpw
CL = 50 pF, VDD = 2.7 V to 3.6 V
CL = 50 pF, VDD = 2 V to 2.7 V
CL = 30 pF, VDD = 2.7 V to 3.6 V
CL = 50 pF, VDD = 2.7 V to 3.6 V
CL = 50 pF, VDD = 2 V to 2.7 V
ns
Output low to high
level rise time
Pulse width of
external signals
detected by the EXTI
controller
-
10
ns
1. The I/O speed is configured using the MODEx[1:0] bits. Refer to the STM32F10xxx reference manual for a
description of GPIO Port configuration register.
2. The maximum frequency is defined in Figure 17.
3. Guaranteed by design, not tested in production.
Doc ID 15274 Rev 4
55/95
