Register set
ST10F276E
22.9
Flash registers ordered by address
Table 72 lists by order of their physical addresses all Flash control registers which are
implemented in the ST10F276E. Note that as they are physically mapped on the X-Bus,
these registers are not bit-addressable.
Table 72. Flash registers ordered by address
Physical
Name
Description
Reset value
address
FCR0L
0x000E 0000 Flash control register 0 - Low
0x000E 0002 Flash control register 0 - High
0x000E 0004 Flash control register 1 - Low
0x000E 0006 Flash control register 1 - High
0x000E 0008 Flash data register 0 - Low
0000h
0000h
0000h
0000h
FFFFh
FFFFh
FFFFh
FFFFh
0000h
0000h
0000h
FFFFh
FFFFh
FFFFh
FFFFh
ACFFh
FCR0H
FCR1L
FCR1H
FDR0L
FDR0H
0x000E 000A Flash data register 0 - High
0x000E 000C Flash data register 1 - Low
0x000E 000E Flash data register 1 - High
0x000E 0010 Flash address register Low
0x000E 0012 Flash address register High
0x000E 0014 Flash error register
FDR1L
FDR1H
FARL
FARH
FER
FNVWPXRL
FNVWPXRH
FNVWPIRL
FNVWPIRH
FNVAPR0
0x000E DFB0 Flash nonvolatile protection X reg. Low
0x000E DFB2 Flash nonvolatile protection X reg. High
0x000E DFB4 Flash nonvolatile protection I reg. Low
0x000E DFB6 Flash nonvolatile protection I reg. High
0x000E DFB8 Flash nonvolatile access protection reg. 0
Flash nonvolatile access protection reg. 1 -
FNVAPR1L
0x000E DFBC
Low
FFFFh
Flash nonvolatile access protection reg. 1 -
FNVAPR1H
XFICR
0x000E DFBE
High
FFFFh
000Fh
0x000E E000 XFlash interface control register
166/235
Doc ID 12303 Rev 3
