Programming manual
powerSTEP01
Table 19. Maximum fast decay times (continued)
TOFF_FAST [3..0] FAST_STEP[3..0] Fast decay time
28 μs
32 μs
1
1
1
1
1
1
0
1
Any attempt to write to the register when the motor is running causes the command to be
ignored and NOTPERF_CMD to rise (Section 11.1.28).
11.1.18 TON_MIN
This register is specific for current mode driving (see Section 9).
This parameter is used by the current control system when current mode operation is
selected.
The TON_MIN register contains the minimum on-time value used by the current control
system (see Section 9.2).
The available range for both parameters is from 0.5 μs to 64 μs.
Table 20. Minimum on-time
TON MIN [6..0]
Time
0
0
0
0
0
0
0
0
0
0
0
0
0
1
0.5 μs
1 μs
1
1
1
1
1
1
1
1
1
1
1
1
0
1
63.5 μs
64 μs
Any attempt to write to the register when the motor is running causes the command to be
ignored and the NOTPERF_CMD to rise (see Section 11.1.28).
11.1.19 TOFF_MIN
This register is specific for current mode driving (see Section 9).
This parameter is used by the current control system when current mode operation is
selected.
The TOFF_MIN register contains the minimum off-time value used by the current control
system (see Section 9.1 for details).
The available range for both parameters is from 0.5 μs to 64 μs.
Table 21. Minimum off-time
TOFF MIN [6..0]
Time
0
0
0
0
0
0
0
0
0
0
0
0
0
1
0.5 μs
1 μs
60/90
DocID025022 Rev 1
