L6599A
Electrical characteristics
Min. Typ. Max. Unit
Table 5.
Symbol
Electrical characteristics (continued)
Parameter Test condition
Low-side gate driver (voltages referred to GND)
VLVGL
VLVGH
Output low voltage
Output high voltage
Isink = 200 mA
Isource = 5 mA
1.5
V
V
12.8
-0.3
0.8
13.3
Isourcepk Peak source current
A
Isinkpk
Peak sink current
Fall time
A
tf
tr
30
60
ns
ns
Rise time
Vcc = 0 to VccOn
Isink = 2 mA
,
UVLO saturation
1.1
1.5
V
High-side gate driver (voltages referred to OUT)
VLVGL
VLVGH
Output low voltage
Output high voltage
Isink = 200 mA
Isource = 5 mA
V
V
12.8
-0.3
0.8
13.3
Isourcepk Peak source current
A
Isinkpk
Peak sink current
Fall time
A
tf
tr
30
60
25
ns
ns
kΩ
Rise time
HVG-OUT pull-down
1. Values tracking each other.
Doc ID 15308 Rev 7
11/35
