HCC/HCF4051B/52B/53B
FUNCTIONAL DIAGRAMS AND TRUTH TABLES (continued)
4053
A or B
or C
Inhibit
0
0
1
0
1
ax or bx or cx
ay or by or cy
None
X
X = Don’t care.
ABSOLUTE MAXIMUM RATINGS
Symbol
Parameter
Supply Voltage : HCC Types
HCF Types
Value
Unit
VDD
*
– 0.5 to + 20
– 0.5 to + 18
V
V
Vi
II
Input Voltage
– 0.5 to VDD + 0.5
V
DC Input Current (any one input)
± 10
mA
mW
Pt ot
Total Power Dissipation (per package)
Dissipation per Output Transistor
200
for Top = Full Package-temperature Range
100
mW
To p
Tstg
Operating Temperature : HCC Types
HCF Types
– 55 to + 125
– 40 to + 85
°C
°C
Storage Temperature
– 65 to + 150
°C
Stresses above those listed under ”Absolute Maximum Ratings” may cause permanent damage to the device. This is a stress
rating only and functional operation of the device at these or any other conditions above those indicated in the operational sec-
tions of this specification is not implied. Exposure to absolute maximum rating conditions for external periods may affect device
reliability.
* All voltage values are referred to VSS pin voltage.
RECOMMENDED OPERATING CONDITIONS
Symbol
Parameter
Supply Voltage : HCC Types
HCF Types
Value
Unit
VDD
3 to 18
3 to 15
V
V
VI
Input Voltage
0 to VDD
V
To p
Operating Temperature : HCC Types
HCF Types
– 55 to + 125
– 40 to + 85
°C
°C
