A d v a n c e I n f o r m a t i o n
START
Read DQ7–DQ0
Read DQ7–DQ0
No
Toggle Bit
= Toggle?
Yes
No
DQ5 = 1?
Yes
Read DQ7–DQ0
Twice
Toggle Bit
= Toggle?
No
Yes
Program/Erase
Operation Not
Program/Erase
Operation Complete
Complete, Write
Reset Command
Note:
The system should recheck the toggle bit even if
DQ5 = “1” because the toggle bit may stop toggling
as DQ5 changes to “1.” See the subsections on DQ6
and DQ2 for more information.
Figure 6. Toggle Bit Algorithm
DQ2: Toggle Bit II
The “Toggle Bit II” on DQ2, when used with DQ6, indicates whether a particular
sector is actively erasing (that is, the Embedded Erase algorithm is in progress),
or whether that sector is erase-suspended. Toggle Bit II is valid after the rising
edge of the final WE# pulse in the command sequence.
DQ2 toggles when the system reads at addresses within those sectors that have
been selected for erasure. (The system may use either OE# or CE# to control the
82
S29GLxxxN MirrorBitTM Flash Family
27631A4 May 13, 2004
