Three Port 10/100 Managed Ethernet Switch with MII
Datasheet
8.2.3.5
EWEN (Erase/Write Enable)
This command enables the EEPROM for erase and write operations. The EEPROM will allow erase
and write operations until the EWDS command is sent, or until power is cycled.
Note: The EEPROM will power-up in the erase/write disabled state. Any erase or write operations
will fail until an EWEN command is issued.
EECS
EECLK
EEDO
EEDI
1
0
0
1
1
Figure 8.10 EEPROM EWEN Cycle
8.2.3.6
READ (Read Location)
This command will cause a read of the EEPROM location pointed to by the EPC_ADDRESS field of
the EEPROM Command Register (E2P_CMD). The result of the read is available in the EEPROM Data
Register (E2P_DATA).
EECS
EECLK
EEDO
EEDI
1
1
0
Ax
A0
D7
D0
Figure 8.11 EEPROM READ Cycle
SMSC LAN9313/LAN9313i
111
Revision 1.2 (04-08-08)
DATASHEET
