Figure 8.1 illustrates the process required to perform an EEPROM read or write operation.
EEPROM Write
EEPROM Read
Idle
Idle
Write
Write
E2P_DATA
Register
E2P_CMD
Register
Write
Read
E2P_CMD
Register
E2P_CMD
Register
EPC_BUSY = 0
Read
Read
E2P_CMD
Register
E2P_DATA
Register
EPC_BUSY = 0
Figure 8.1 EEPROM Access Flow Diagram
2
8.2.2
I C EEPROM
The I2C master implements a low level serial interface (start and stop condition generation, data bit
transmission and reception, acknowledge generation and reception) for connection to I2C EEPROMs,
and consists of a data wire (EE_SDA) and a serial clock (EE_SCL). The serial clock is driven by the
master, while the data wire is bi-directional. Both signals are open-drain and require external pull-up
resistors.
The serial clock is also used as an input as it can be held low by the slave device in order to wait-
state the data cycle. Once the slave has data available or is ready to receive, it will release the clock.
Assuming the masters clock low time is also expired, the clock will rise and the cycle will continue. In
the event that the slave device holds the clock low for more than 30mS, the current command
sequence is aborted and the EPC_TIMEOUT bit in the EEPROM Command Register (E2P_CMD) is
set. Both the clock and data signals have Schmitt trigger inputs and digital input filters. The digital filters
reject pulses that are less than 100nS.
Note: Since the I2C master is designed to access EEPROM only, multi-master arbitration is not
supported.
Based on the configuration strap eeprom_size_strap, various sized I2C EEPROMs are supported. The
varying size ranges are supported by additional bits in the address field (EPC_ADDRESS) of the
EEPROM Command Register (E2P_CMD). Within each size range, the largest EEPROM uses all the
address bits, while the smaller EEPROMs treat the upper address bits as don’t cares. The EEPROM
