Highly Efficient Single-Chip 10/100 Non-PCI Ethernet Controller
Datasheet
Table 3.2 Wake-Up Frame Filter Register Structure
Filter 0 Byte Mask
Filter 1 Byte Mask
Filter 2 Byte Mask
Filter 3 Byte Mask
Reserved
Filter 3
Reserved
Filter 2
Reserved
Filter 1
Reserved
Filter 0
Command
Command
Command
Command
Filter 3 Offset
Filter 1 CRC-16
Filter 3 CRC-16
Filter 2 Offset
Filter 1Offset
Filter 0 Offset
Filter 0 CRC-16
Filter 2 CRC-16
The Filter i Byte Mask defines which incoming frame bytes Filter i will examine to determine whether
or not this is a wake-up frame. Table 3.3, describes the byte mask’s bit fields.
Table 3.3 Filter i Byte Mask Bit Definitions
FILTER I BYTE MASK DESCRIPTION
FIELD
DESCRIPTION
31
Must be zero (0)
30:0
Byte Mask: If bit j of the byte mask is set, the CRC machine processes byte number pattern - (offset
+ j) of the incoming frame. Otherwise, byte pattern - (offset + j) is ignored.
The Filter i command register controls Filter i operation. Table 3.4 shows the Filter I command register.
Table 3.4 Filter i Command Bit Definitions
FILTER i COMMANDS
FIELD
DESCRIPTION
3
Address Type: Defines the destination address type of the pattern. When bit is set, the pattern
applies
only to multicast frames. When bit is cleared, the pattern applies only to unicast frames.
2:1
0
RESERVED
Enable Filter: When bit is set, Filter i is enabled, otherwise, Filter i is disabled.
The Filter i Offset register defines the offset in the frame’s destination address field from which the
frames are examined by Filter i. Table 3.5 describes the Filter i Offset bit fields.
