NAME
REG INDEX
DEFINITION
Bit[7] Output Type Select
STATE
1=Open Drain
0=Push Pull Bit
GP17
0xE7
General Purpose I/0 bit 1.7
Bit[0] In/Out : =1 Input, =0 Output
Bit[1] Polarity : =1 Invert, =0 No Invert
Bit[2] Group Interrupt Enable
=1 Enable Combined IRQ 1
=0 Disable Combined IRQ 1
Bit[3] Function Select
=1 nDS1
C
Default = 0x01
on Vbat POR
=0 GPI/O
Bits[6:4] Reserved
Bit[7] Output Type Select
1=Open Drain
0=Push Pull
GP50
0xC8
General Purpose I/0 bit 5.0
Bit[0] In/Out : =1 Input, =0 Output
Bit[1] Polarity : =1 Invert, =0 No Invert
Bit[2] Reserved
Default = 0x01
on Vbat POR
Bit[4:3] Function Select
=00 PCI Clock
=01 IRQ14
=10 GPI/O
=11 Reserved
Bit[5] Group Interrupt Enable
=1 Enable Combined IRQ 2
=0 Disable Combined IRQ 2
Bit[6] Reserved
Bit[7] Output Type Select
1=Open Drain
0=Push Pull
GP52
0xCA
General Purpose I/0 bit 5.2
Bit[0] In/Out : =1 Input, =0 Output
Bit[1] Polarity : =1 Invert, =0 No Invert
Bit[2] Reserved
Default =0x09
on Vbat POR
Bit[4:3] Function Select
=00 DRVDEN1
=01 GPIO
=10 IRQ8
=11 nSMI
Bit[5] Group Interrupt Enable
=1 Enable Combined IRQ 2
=0 Disable Combined IRQ 2
Bit[6] Reserved
Bit[7] Output Type Select
1=Open Drain
204
