ST7735
10.1.28 IDMON (39h): Idle Mode On
39H
IDMON (Idle Mode On)
Inst / Para
IDMOFF
D/CX
0
WRX
RDX
1
D17-8
-
D7
0
D6
0
D5
1
D4
1
D3
1
D2
0
D1
0
D0
1
HEX
(39h)
-
↑
Parameter
No Parameter
-This command is used to enter into Idle mode on.
-There will be no abnormal visible effect on the display mode change transition.
-In the idle on mode,
1. Color expression is reduced. The primary and the secondary colors using MSB of each R,G and B in the Frame
Memory, 8 color depth data is displayed.
2. 8-Color mode frame frequency is applied.
3. Exit from IDMON by Idle Mode Off (38h) command
(Example) Memory
Display
Top-Left (0,0)
Description
Color
Black
Blue
Red
R5 R4 R3 R2 R1 R0
0xxxxx
G5 G4 G3 G2 G1 G0
0xxxxx
B5 B4 B3 B4 B1 B0
0xxxxx
0xxxxx
0xxxxx
1xxxxx
1xxxxx
0xxxxx
0xxxxx
Magenta
Green
Cyan
1xxxxx
0xxxxx
1xxxxx
0xxxxx
1xxxxx
0xxxxx
0xxxxx
1xxxxx
1xxxxx
Yellow
White
1xxxxx
1xxxxx
0xxxxx
1xxxxx
1xxxxx
1xxxxx
Status
Availability
Normal Mode On, Idle Mode Off, Sleep Out
Normal Mode On, Idle Mode On, Sleep Out
Partial Mode On, Idle Mode Off, Sleep Out
Partial Mode On, Idle Mode On, Sleep Out
Sleep In
Yes
Yes
No
Register
Availability
No
Yes
Status
Default Value
Idle Mode Off
Idle Mode Off
Idle Mode Off
Power On Sequence
S/W Reset
Default
H/W Reset
V1.7
112
2009-12-04
