ST7669V
9.1.53 BstPmpXSel: Booster Set(C4H)
Command
A0
0
/RD /WR
D7
1
D6
1
D5
0
D4
0
D3
0
D2
D1
D0
Hex
(C4h)
BstPmpXSel
Parameter
1
1
0
0
1
0
0
-
BST2 BST 1 BST0
1
-
-
-
-
-
NOTE: “-“ Don’t care
Description
Booster setting
BST2 BST1 BST0
X1 boosting circuit
(Booster off)
0
0
0
0
0
0
1
1
1
1
0
1
1
0
0
1
1
1
0
1
0
1
0
1
X2 boosting circuit
X3 boosting circuit
X4 boosting circuit
X5 boosting circuit
X6 boosting circuit
X7 boosting circuit
X8 boosting circuit
Restriction
Register
Status
Availability
Yes
Availability
Normal Mode On, Idle Mode Off, Sleep Out
Normal Mode On, Idle Mode On, Sleep Out
Partial Mode On, Idle Mode Off, Sleep Out
Partial Mode On, Idle Mode On, Sleep Out
Sleep In
Yes
Yes
Yes
Yes
Default
Status
Default Value (BST[2:0])
Power On Sequence
S/W Reset
111b
111b
111b
H/W Reset
Ver 1.3
148/208
6/4/2008
