ST7669V
9.1.55 VopOffset: Vop offset fuse bit adjust(C7H)
Command
A0
0
/RD /WR
D7
1
D6
D5
D4
D3
D2
D1
D0
Hex
(C7h)
-
VopOffset
1
1
0
0
1
0
0
0
1
1
1
Parameter
1
-
VOS6 VOS5 VOS4 VOS3 VOS2 VOS1 VOS0
NOTE: “-“ Don’t care
Description
The command is used to the Vop offset for V0. For VOS[6:0] setting, please see the following
table:
VOS[6]
VOS[5:0]
111111
111110
111101
…
(Dec)
63
62
61
…
V0 Offset
+2520 mV
+2480 mV
+2440 mV
…
0
000010
000001
000000
111111
111110
…
2
+80 mV
+40 mV
0 mV
1
0
-1
-40 mV
-80 mV
…
-2
…
1
000010
000001
000000
-61
-62
-63
-2440 mV
-2480 mV
-2520 mV
Restriction
Register
Status
Availability
Availability
Normal Mode On, Idle Mode Off, Sleep Out
Normal Mode On, Idle Mode On, Sleep Out
Partial Mode On, Idle Mode Off, Sleep Out
Partial Mode On, Idle Mode On, Sleep Out
Sleep In
Yes
Yes
Yes
Yes
Yes
Default
Status
Default Value
VOS6
VOS[5:0]
Power On Sequence
S/W Reset
0
0
0
0
0
0
H/W Reset
Ver 1.3
151/208
6/4/2008
