ST7628
9.1.38 RDID3: Read ID3 Value (DCh)
Command
RDID3
A0
0
/RD /WR
D7
D6
D5
D4
D3
D2
D1
D0
Hex
(DCh)
1
1
0
1
1
1
0
0
1
0
0
0
1
1
-
-
1
-
-
-
-
-
-
-
-
Dummy Read
1
ID37 ID36 ID35 ID34 ID33 ID32 ID31 ID30
2
nd parameter
NOTE: “-“ Don’t care
Description
This read byte returns 8-bit LCD module/driver ID.
D7-D0 (ID37 to ID30): LCD module/driver ID.
NOTE: See command RDDID (04h), 4th parameter.
Restriction
Register
Availability
Status
Availability
Normal Mode On, Idle Mode Off, Sleep Out
Normal Mode On, Idle Mode On, Sleep Out
Partial Mode On, Idle Mode Off, Sleep Out
Partial Mode On, Idle Mode On, Sleep Out
Sleep In
Yes
Yes
Yes
Yes
Yes
Default
Status
Default Value
0Eh
Power On Sequence
S/W Reset
0Eh
H/W Reset
0Eh
Flow Chart
Ver 1.4
141/213
2008/08
