ST7628
9.1.36 RDID1: Read ID1 Value (DAh)
Command
RDID1
A0
0
/RD /WR
D7
1
D6
1
D5
0
D4
1
D3
1
D2
0
D1
1
D0
0
Hex
(DAh)
1
0
0
0
1
1
-
-
1
-
-
-
-
-
-
-
-
Dummy Read
1
ID17 ID16 ID15 ID14 ID13 ID12 ID11 ID10
2
nd parameter
NOTE: “-“ Don’t care
Description
This read byte returns 8-bit LCD module’s manufacturer ID
D7-D0 (ID17 to ID10): LCD module’s manufacturer ID.
NOTE: See command RDDID (04h), 2nd parameter.
Restriction
Register
Status
Availability
Yes
Availability
Normal Mode On, Idle Mode Off, Sleep Out
Normal Mode On, Idle Mode On, Sleep Out
Partial Mode On, Idle Mode Off, Sleep Out
Partial Mode On, Idle Mode On, Sleep Out
Sleep In
Yes
Yes
Yes
Yes
Default
Status
Default Value
Power On Sequence
45h
45h
45h
S/W Reset
H/W Reset
Flow Chart
Ver 1.4
139/213
2008/08
