ST7628
9.1.42 PTLMOD: Partial Saving Power Mode Selection (B4H)
Command
A0
0
/RD /WR
D7
1
D6
0
D5
1
D4
1
D3
0
D2
1
D1
0
D0
0
Hex
(B4h)
-
1
1
0
0
OscDiv
1
PTLM
0
0
1
1
0
0
0
Parameter
NOTE: “-“ Don’t care
Description
Two type partial modes are built in ST7628. One is NORMAL MODE(PTLM=0) and another is
POWER SAVING MODE(PTML=1). When entering power saving mode, IC would change bias, V0,
booster pumping times in 4 special partial lines in order to save power consumptions, please see the
following table:
Duty
24
Bias
1/6
Bst pump
V0(V)
5x
5x
5x
5x
9+(Vopoffset/2)
32
1/6
9.68+(Vopoffset/2)
10.12+(Vopoffset/2)
10.52+(Vopoffset/2)
40
1/6
48
1/6
Restriction
Register
Status
Availability
Availability
Normal Mode On, Idle Mode Off, Sleep Out
Normal Mode On, Idle Mode On, Sleep Out
Partial Mode On, Idle Mode Off, Sleep Out
Partial Mode On, Idle Mode On, Sleep Out
Sleep In
Yes
Yes
Yes
Yes
Yes
Default
Status
Default Value
18h
Power On Sequence
S/W Reset
18h
H/W Reset
18h
Flow Chart
Ver 1.4
145/213
2008/08
