PACKAGE: PLASTIC SHRINK
SMALL OUTLINE
(SSOP)
E
H
D
A
Ø
A1
L
e
B
DIMENSIONS (Inches)
Minimum/Maximum
(mm)
16–PIN
24–PIN
20–PIN
28–PIN
0.068/0.078
(1.73/1.99)
0.068/0.078
(1.73/1.99)
A
A1
B
D
E
0.068/0.078
(1.73/1.99)
0.068/0.078
(1.73/1.99)
0.002/0.008
(0.05/0.21)
0.002/0.008
(0.05/0.21)
0.002/0.008
(0.05/0.21)
0.002/0.008
(0.05/0.21)
0.010/0.015
(0.25/0.38)
0.010/0.015
(0.25/0.38)
0.010/0.015
(0.25/0.38)
0.010/0.015
(0.25/0.38)
0.239/0.249
(6.07/6.33)
0.317/0.328
(8.07/8.33)
0.278/0.289
(7.07/7.33)
0.397/0.407
(10.07/10.33)
0.205/0.212
(5.20/5.38)
0.205/0.212
(5.20/5.38)
0.205/0.212
(5.20/5.38)
0.205/0.212
(5.20/5.38)
0.0256 BSC
(0.65 BSC)
0.0256 BSC
(0.65 BSC)
e
0.0256 BSC
(0.65 BSC)
0.0256 BSC
(0.65 BSC)
0.301/0.311
(7.65/7.90)
0.301/0.311
(7.65/7.90)
H
L
0.301/0.311
(7.65/7.90)
0.301/0.311
(7.65/7.90)
0.022/0.037
(0.55/0.95)
0.022/0.037
(0.55/0.95)
0.022/0.037
(0.55/0.95)
0.022/0.037
(0.55/0.95)
0°/8°
(0°/8°)
0°/8°
(0°/8°)
Ø
0°/8°
(0°/8°)
0°/8°
(0°/8°)
Date: 6/2/04
SP3223EB/3243EB +3.0V to +5.5V RS-232 Transceivers
© Copyright 2004 Sipex Corporation
21
