EFR32MG13 Mighty Gecko Multi-Protocol Wireless SoC Family Data Sheet
Electrical Specifications
4.1.15 Voltage Monitor (VMON)
Table 4.46. Voltage Monitor (VMON)
Parameter
Symbol
IVMON
Test Condition
Min
Typ
Max
Unit
Supply current (including
I_SENSE)
In EM0 or EM1, 1 active channel,
T ≤ 85 °C
—
6.3
8
µA
In EM0 or EM1, 1 active channel,
T > 85 °C
—
—
—
—
—
—
—
—
12.5
—
10
15
18
—
—
—
—
µA
µA
µA
nA
nA
nA
nA
In EM0 or EM1, All channels ac-
tive, T ≤ 85 °C
In EM0 or EM1, All channels ac-
tive, T > 85 °C
In EM2, EM3 or EM4, 1 channel
active and above threshold
62
In EM2, EM3 or EM4, 1 channel
active and below threshold
62
In EM2, EM3 or EM4, All channels
active and above threshold
99
In EM2, EM3 or EM4, All channels
active and below threshold
99
Loading of monitored supply ISENSE
In EM0 or EM1
—
—
2
2
—
—
3.4
—
—
—
—
µA
nA
V
In EM2, EM3 or EM4
Threshold range
VVMON_RANGE
1.62
—
—
Threshold step size
NVMON_STESP
Coarse
200
20
460
26
mV
mV
ns
Fine
—
Response time
Hysteresis
tVMON_RES
Supply drops at 1V/µs rate
—
VVMON_HYST
—
mV
silabs.com | Building a more connected world.
Rev. 1.4 | 91
