EFR32MG13 Mighty Gecko Multi-Protocol Wireless SoC Family Data Sheet
Electrical Specifications
4.1.9.5 RF Transmitter Characteristics for Bluetooth Low Energy in the 2.4GHz Band, 2 Mbps Data Rate
Unless otherwise indicated, typical conditions are: T = 25 °C, VREGVDD = AVDD = IOVDD = 3.3 V, DVDD = RFVDD = PAVDD.
RFVDD and PAVDD path is filtered using ferrites. Crystal frequency = 38.4MHz. RF center frequency 2.45 GHz. Maximum duty cycle of
85%.
Table 4.16. RF Transmitter Characteristics for Bluetooth Low Energy in the 2.4GHz Band, 2 Mbps Data Rate
Parameter
Symbol
TXBW
Test Condition
Min
—
Typ
1395
-12.7
Max
—
Unit
Transmit 6dB bandwidth
Power spectral density limit
10 dBm
kHz
PSDLIMIT
Per FCC part 15.247 at 10 dBm
—
—
dBm/
3kHz
Per FCC part 15.247 at 20 dBm
—
—
—
-4.7
10
—
—
—
dBm/
3kHz
Per ETSI 300.328 at 10 dBm/1
MHz
dBm
Occupied channel bandwidth OCPETSI328
per ETSI EN300.328
99% BW at highest and lowest
channels in band, 10 dBm
2.1
MHz
In-band spurious emissions, SPURINB
with allowed exceptions1
At ± 4 MHz, 10 dBm
At ± 6 MHz, 10 dBm
At ± 4 MHz, 20 dBm
At ± 6 MHz, 20 dBm
—
—
—
—
—
-40.9
-44.8
-32.3
-36.6
-47
—
—
—
—
—
dBm
dBm
dBm
dBm
dBm
Emissions of harmonics out- SPURHRM_FCC 2nd,3rd, 5, 6, 8, 9,10 harmonics;
of-band, per FCC part
15.247
continuous transmission of modu-
lated carrier
Spurious emissions out-of-
band, excluding harmonics
captured in SPURHARM,FCC
Emissions taken at
POUTMAX, PAVDD connec-
ted to external 3.3 V supply
SPUROOB_FCC
Per FCC part 15.205/15.209,
Above 2.483 GHz or below 2.4
GHz; continuous transmission of
—
—
-47
-26
—
—
dBm
dBc
.
CW carrier, Restricted Bands2 3 4
5
Per FCC part 15.247, Above
2.483 GHz or below 2.4 GHz;
continuous transmission of CW
carrier, Non-Restricted Bands
Spurious emissions out-of-
band; per ETSI 300.328
SPURETSI328
[2400-BW to 2400] MHz, [2483.5
to 2483.5+BW] MHz
—
—
-16
-26
—
—
dBm
dBm
[2400-2BW to 2400-BW] MHz,
[2483.5+BW to 2483.5+2BW]
MHz per ETSI 300.328
Spurious emissions per ETSI SPURETSI440
EN300.440
47-74 MHz,87.5-108 MHz,
174-230 MHz, 470-862 MHz
—
-60
—
dBm
25-1000 MHz
1-12 GHz
—
—
-42
-36
—
—
dBm
dBm
