EFR32MG13 Mighty Gecko Multi-Protocol Wireless SoC Family Data Sheet
Electrical Specifications
4.1.9.8 RF Receiver Characteristics for Bluetooth Low Energy in the 2.4GHz Band, 500 kbps Data Rate
Unless otherwise indicated, typical conditions are: T = 25 °C, VREGVDD = AVDD = IOVDD = 3.3 V, DVDD = RFVDD = PAVDD.
RFVDD and PAVDD path is filtered using ferrites. Crystal frequency = 38.4MHz. RF center frequency 2.45 GHz.
Table 4.19. RF Receiver Characteristics for Bluetooth Low Energy in the 2.4GHz Band, 500 kbps Data Rate
Parameter
Symbol
Test Condition
Min
Typ
Max
Unit
Signal is reference signal1. Packet
length is 20 bytes.
Max usable receiver input
level, 0.1% BER
SAT
—
10
—
dBm
Signal is reference signal1. Using
DC-DC converter.
Sensitivity, 0.1% BER
SENS
—
—
-99
—
—
dBm
dBm
With non-ideal signals as speci-
fied in RF-PHY.TS.4.2.2, section
4.6.1.
-98.2
N+1 adjacent channel selec- C/I1+
tivity, 0.1% BER, with allowa-
ble exceptions. Desired is
Interferer is reference signal at +1
MHz offset. Desired frequency
2402 MHz ≤ Fc ≤ 2480 MHz
—
—
—
-9
-9
—
—
—
dB
dB
dB
reference signal at -72 dBm
N-1 adjacent channel selec- C/I1-
tivity, 0.1% BER, with allowa-
ble exceptions. Desired is
Interferer is reference signal at -1
MHz offset. Desired frequency
2402 MHz ≤ Fc ≤ 2480 MHz
reference signal at -72 dBm
Alternate selectivity, 0.1%
BER, with allowable excep-
tions. Desired is reference
signal at -72 dBm
C/I2
Interferer is reference signal at ± 2
MHz offset. Desired frequency
2402 MHz ≤ Fc ≤ 2480 MHz
-50.8
Selectivity to image frequen- C/IIM
cy, 0.1% BER. Desired is ref-
erence signal at -72 dBm
Interferer is reference signal at im-
age frequency with 1 MHz preci-
sion
—
—
-46.2
-56.1
—
—
dB
dB
Selectivity to image frequen- C/IIM+1
cy ± 1 MHz, 0.1% BER. De-
sired is reference signal at
-72 dBm
Interferer is reference signal at im-
age frequency ± 1 MHz with 1
MHz precision
Intermodulation performance IM
Per Core_4.1, Vol 6, Part A, Sec-
tion 4.4 with n = 3
—
-22.7
—
dBm
Note:
1. Reference signal is defined 2GFSK at -72 dBm, Modulation index = 0.5, BT = 0.5, Bit rate = 500 kbps, desired data = PRBS9;
interferer data = PRBS15; frequency accuracy better than 1 ppm.
