EFR32MG13 Mighty Gecko Multi-Protocol Wireless SoC Family Data Sheet
Electrical Specifications
4.1.9.3 RF Transmitter Characteristics for Bluetooth Low Energy in the 2.4GHz Band, 1 Mbps Data Rate
Unless otherwise indicated, typical conditions are: T = 25 °C, VREGVDD = AVDD = IOVDD = 3.3 V, DVDD = RFVDD = PAVDD.
RFVDD and PAVDD path is filtered using ferrites. Crystal frequency = 38.4MHz. RF center frequency 2.45 GHz. Maximum duty cycle of
85%.
Table 4.14. RF Transmitter Characteristics for Bluetooth Low Energy in the 2.4GHz Band, 1 Mbps Data Rate
Parameter
Symbol
TXBW
Test Condition
Min
—
Typ
763
-9.1
Max
—
Unit
Transmit 6dB bandwidth
Power spectral density limit
10 dBm
kHz
PSDLIMIT
Per FCC part 15.247 at 10 dBm
—
—
dBm/
3kHz
Per FCC part 15.247 at 20 dBm
—
—
—
-2
10
1.1
—
—
—
dBm/
3kHz
Per ETSI 300.328 at 10 dBm/1
MHz
dBm
Occupied channel bandwidth OCPETSI328
per ETSI EN300.328
99% BW at highest and lowest
channels in band, 10 dBm
MHz
In-band spurious emissions, SPURINB
with allowed exceptions1
At ± 2 MHz, 10 dBm
At ± 3 MHz, 10 dBm
At ± 2 MHz, 20 dBm
At ± 3 MHz, 20 dBm
—
—
—
—
—
-39.5
-44.3
—
—
—
dBm
dBm
dBm
dBm
dBm
-20
-30
—
—
Emissions of harmonics out- SPURHRM_FCC 2nd,3rd, 5, 6, 8, 9,10 harmonics;
-47
of-band, per FCC part
15.247
continuous transmission of modu-
lated carrier
Spurious emissions out-of-
band, excluding harmonics
captured in SPURHARM,FCC
Emissions taken at
POUTMAX, PAVDD connec-
ted to external 3.3 V supply
SPUROOB_FCC
Per FCC part 15.205/15.209,
Above 2.483 GHz or below 2.4
GHz; continuous transmission of
—
—
-47
-26
—
—
dBm
dBc
.
CW carrier, Restricted Bands2 3
Per FCC part 15.247, Above
2.483 GHz or below 2.4 GHz;
continuous transmission of CW
carrier, Non-Restricted Bands
Spurious emissions out-of-
band; per ETSI 300.328
SPURETSI328
[2400-BW to 2400] MHz, [2483.5
to 2483.5+BW] MHz
—
—
-16
-26
—
—
dBm
dBm
[2400-2BW to 2400-BW] MHz,
[2483.5+BW to 2483.5+2BW]
MHz per ETSI 300.328
Spurious emissions per ETSI SPURETSI440
EN300.440
47-74 MHz,87.5-108 MHz,
174-230 MHz, 470-862 MHz
—
-60
—
dBm
25-1000 MHz
1-12 GHz
—
—
-42
-36
—
—
dBm
dBm
Note:
1. Per Bluetooth Core_5.0, Vol.6 Part A, Section 3.2.2, exceptions are allowed in up to three bands of 1 MHz width, centered on a
frequency which is an integer multiple of 1 MHz. These exceptions shall have an absolute value of -20 dBm or less.
2. For 2476 MHz, 1.5 dB of power backoff is used to achieve this value.
3. For 2478 MHz, 4.2 dB of power backoff is used to achieve this value.
