EFR32MG13 Mighty Gecko Multi-Protocol Wireless SoC Family Data Sheet
Electrical Specifications
4.1.6 Wake Up Times
Table 4.9. Wake Up Times
Parameter
Symbol
Test Condition
Min
Typ
Max
Unit
Wake up time from EM1
tEM1_WU
—
3
—
AHB
Clocks
Wake up from EM2
Wake up from EM3
tEM2_WU
Code execution from flash
Code execution from RAM
Code execution from flash
Code execution from RAM
Executing from flash
—
—
—
—
—
10.9
3.8
—
—
—
—
—
µs
µs
µs
µs
µs
tEM3_WU
10.9
3.8
Wake up from EM4H1
Wake up from EM4S1
tEM4H_WU
tEM4S_WU
tRESET
90
Executing from flash
—
300
—
µs
Time from release of reset
source to first instruction ex-
ecution
Soft Pin Reset released
Any other reset released
—
—
51
—
—
µs
µs
358
Power mode scaling time
tSCALE
VSCALE0 to VSCALE2, HFCLK =
19 MHz2 3
—
—
31.8
4.3
—
—
µs
µs
VSCALE2 to VSCALE0, HFCLK =
19 MHz4
Note:
1. Time from wake up request until first instruction is executed. Wakeup results in device reset.
2. Scaling up from VSCALE0 to VSCALE2 requires approximately 30.3 µs + 28 HFCLKs.
3. VSCALE0 to VSCALE2 voltage change transitions occur at a rate of 10 mV/µs for approximately 20 µs. During this transition,
peak currents will be dependent on the value of the DECOUPLE output capacitor, from 35 mA (with a 1 µF capacitor) to 70 mA
(with a 2.7 µF capacitor).
4. Scaling down from VSCALE2 to VSCALE0 requires approximately 2.8 µs + 29 HFCLKs.
