EFR32MG13 Mighty Gecko Multi-Protocol Wireless SoC Family Data Sheet
Electrical Specifications
Parameter
Symbol
Test Condition
Min
Typ
Max
Unit
Current consumption in
transmit mode (MCU in EM1
@ 38.4 MHz, peripheral
clocks disabled), T ≤ 85 °C
ITX
F = 915 MHz, CW, 20 dBm
match, External PA supply = 3.3V
—
90.2
134.3
mA
F = 915 MHz, CW, 14 dBm
match, External PA supply con-
nected to DCDC output
—
36
42.5
mA
F = 868 MHz, CW, 20 dBm
match, External PA supply = 3.3V
—
—
79.7
35.3
106.7
41
mA
mA
F = 868 MHz, CW, 14 dBm
match, External PA supply con-
nected to DCDC output
F = 490 MHz, CW, 20 dBm
match, External PA supply = 3.3V
—
—
93.8
20.3
125.4
24
mA
mA
F = 433 MHz, CW, 10 dBm
match, External PA supply con-
nected to DC-DC output
F = 433 MHz, CW, 14 dBm
match, External PA supply con-
nected to DCDC output
—
—
34
41.5
42
mA
mA
F = 315 MHz, CW, 14 dBm
match, External PA supply con-
nected to DCDC output
33.5
F = 169 MHz, CW, 20 dBm
match, External PA supply = 3.3V
—
—
—
—
—
—
—
88.6
8.5
116.7
—
mA
mA
mA
mA
mA
mA
mA
F = 2.4 GHz, CW, 0 dBm output
power, Radio clock prescaled by 3
F = 2.4 GHz, CW, 0 dBm output
power, Radio clock prescaled by 1
9.5
—
F = 2.4 GHz, CW, 3 dBm output
power
16.5
26.0
34.0
86.0
—
F = 2.4 GHz, CW, 8 dBm output
power
—
F = 2.4 GHz, CW, 10.5 dBm out-
put power
—
F = 2.4 GHz, CW, 16.5 dBm out-
put power, PAVDD connected di-
rectly to external 3.3V supply
—
F = 2.4 GHz, CW, 19.5 dBm out-
put power, PAVDD connected di-
rectly to external 3.3V supply
—
131.0
—
mA
silabs.com | Building a more connected world.
Rev. 1.4 | 37
