EFR32MG13 Mighty Gecko Multi-Protocol Wireless SoC Family Data Sheet
Electrical Specifications
Parameter
Symbol
Test Condition
Min
Typ
Max
Unit
Current consumption in
transmit mode (MCU in EM1
@ 38.4 MHz, peripheral
clocks disabled), T > 85 °C
ITX_HT
F = 915 MHz, CW, 20 dBm
match, External PA supply = 3.3V
—
—
134.3
mA
F = 915 MHz, CW, 14 dBm
match, External PA supply con-
nected to DCDC output
—
—
42.5
mA
F = 868 MHz, CW, 20 dBm
match, External PA supply = 3.3V
—
—
—
—
109.8
41.3
mA
mA
F = 868 MHz, CW, 14 dBm
match, External PA supply con-
nected to DCDC output
F = 490 MHz, CW, 20 dBm
match, External PA supply = 3.3V
—
—
—
—
130.8
24.4
mA
mA
F = 433 MHz, CW, 10 dBm
match, External PA supply con-
nected to DC-DC output
F = 433 MHz, CW, 14 dBm
match, External PA supply con-
nected to DCDC output
—
—
—
—
—
—
41.5
42
mA
mA
mA
F = 315 MHz, CW, 14 dBm
match, External PA supply con-
nected to DCDC output
F = 169 MHz, CW, 20 dBm
122.8
match, External PA supply = 3.3V
silabs.com | Building a more connected world.
Rev. 1.4 | 38
