C8051F52x-53x
SFR Definition 20.4. PCA0L: PCA Counter/Timer Low Byte
R/W
Bit7
R/W
Bit6
R/W
Bit5
R/W
Bit4
R/W
Bit3
R/W
Bit2
R/W
Bit1
R/W
Reset Value
00000000
Bit0
SFR Address: 0xF9
Bits7–0: PCA0L: PCA Counter/Timer Low Byte.
The PCA0L register holds the low byte (LSB) of the 16-bit PCA Counter/Timer.
SFR Definition 20.5. PCA0H: PCA Counter/Timer High Byte
R/W
Bit7
R/W
Bit6
R/W
Bit5
R/W
Bit4
R/W
Bit3
R/W
Bit2
R/W
Bit1
R/W
Reset Value
00000000
SFR Address:
Bit0
SFR Address: 0xFA
Bits7–0: PCA0H: PCA Counter/Timer High Byte.
The PCA0H register holds the high byte (MSB) of the 16-bit PCA Counter/Timer.
SFR Definition 20.6. PCA0CPLn: PCA Capture Module Low Byte
R/W
Bit7
R/W
R/W
R/W
R/W
R/W
Bit2
R/W
Bit1
R/W
Bit0
Reset Value
00000000
Bit6
Bit5
Bit4
Bit3
SFR Address: PCA0CPL0: 0xFB, PCA0CPL1: 0xE9, PCA0CPL2: 0xEB
Bits7–0: PCA0CPLn: PCA Capture Module Low Byte.
The PCA0CPLn register holds the low byte (LSB) of the 16-bit capture module n.
SFR Definition 20.7. PCA0CPHn: PCA Capture Module High Byte
R/W
Bit7
R/W
R/W
R/W
R/W
R/W
Bit2
R/W
Bit1
R/W
Bit0
Reset Value
00000000
Bit6
Bit5
Bit4
Bit3
SFR Address: PCA0CPH0: 0xFC, PCA0CPH1: 0xE9, PCA0CPH2: 0xEC
Bits7–0: PCA0CPHn: PCA Capture Module High Byte.
The PCA0CPHn register holds the high byte (MSB) of the 16-bit capture module n.
