SK4436
Anything to ECL Receiver
HIGH-PERFORMANCE PRODUCTS
DC Characteristics
(V = - 0.1V to 2.0V; V = 2.0V to 3.6V; VEE = -3.6V to -3.0V; T = 0oC to 70oC)
GG
CC
A
Parameter
Inputs
Symbol
Min
Typ
Max
Units
Input High
Input Low
VIH
VIL
VEE + 2.0
VEE
VCC
V
V
VCC - 0.2
(IN - IN*, CLK - CLK*,
EN - EN*, SEL - SEL*)
Differential Input Voltage
| VIH - VIL |
0.2
4.3
V
Timing Inputs (CLK / CLK*)
Input High Current
IIH
IIL
-5.0
-1
+8.0
<0.5
100
+25
+1
µA
µA
Ω
Input Low Current
IN / IN* Differential Input Resistance
RIN
80
120
Functional Inputs (EN / EN*, SEL / SEL*)
Input Current
IIH, IIL
-500
<200
+500
µA
Outputs
Digital Output Voltage
| OUT - OUT* |
600
780
mV
V
Output Common Mode Range
(OUT + OUT*) / 2
VGG - 1.5 VGG -1.3 VGG - 1.1
Power Supply
IEE
ICC
100
70
150
110
mA
mA
Power Supply Current
DC Test Conditions: Outputs terminated with 50Ω to VGG – 2V.
AC Characteristics
(V = - 0.1V to 2.0V; V = 2.0V to 3.6V; VEE = -3.6V to -3.0V; T = 0oC to 70oC)
GG
CC
A
Parameter
Symbol
Min
Typ
Max
Units
High Performance Option
Propagation Delay
IN[0:3] to OUT[0:3] (SEL = 1)
CLK to OUT[0:3] (SEL = 0)
SEL to OUT [0:3]
Tpd
Tpd
Tpd
Tpd
200
430
300
250
350
550
430
390
550
780
650
600
ps
ps
ps
ps
EN to OUT [0:3]
Channel to Channel Skew
40
80
ps
GHz
ps
1
Maximum Operating Frequency
Fmax
3
1
Minimum Pulse Width
PW min
250
IN to CLK
Set Up Time
Hold Time
Ts
Th
120
120
ps
ps
1
Output Rise and Fall Times (20% / 80%)
Tr / Tf
125
<1
165
ps
1
o
Temperature Coefficient
ps / C
∆Tpd / ∆T
AC Test Conditions: Outputs terminated with 50Ω to VGG – 2V
Note:
1.
Guaranteed by characterization. Not production tested.
Revision 1/July 10, 2002
29
