SK4430
Anything to ECL
HIGH-PERFORMANCE PRODUCTS
DC Characteristics
(V = - 0.1V to 2.0V; V = 2.0V to 3.6V; VEE = -3.6V to -3.0V; T = 0oC to 70oC)
GG
CC
A
Parameter
Inputs
Symbol
Min
Typ
Max
Units
Input High
Input Low
VIH
VIL
VEE + 2.0
VEE
VCC
V
V
VCC - 0.2
(IN - IN*, CLK - CLK*,
EN - EN*, SEL - SEL*)
Differential Input Voltage
| VIH - VIL |
0.2
4.3
V
Timing Inputs (CLK / CLK*)
Input High Current
IIH
IIL
-5.0
-1
+8.0
<0.5
+25
+1
µA
µA
Input Low Current
Timing Inputs (IN / IN*)
IIH, IIL
<40
80
µA
µA
-20
Input High Current, Input Low Current
Functional Inputs (EN / EN*, SEL / SEL*)
Input Current
IIH, IIL
-500
600
<200
+500
Outputs
Digital Output Voltage
Output Common Mode Range
Internal Current Source
Output Impedance
| OUT - OUT* |
780
VGG -1.3
10.0
mV
V
(OUT + OUT*) / 2 VGG - 1.5
VGG - 1.1
13.5
ISINK
ROUT
8.0
40
mA
Ω
50
60
Power Supply
IEE
ICC
190
70
250
110
mA
mA
Power Supply Current
DC Test Conditions: Outputs unterminated.
AC Characteristics
(V = - 0.1V to 2.0V; V = 2.0V to 3.6V; VEE = -3.6V to -3.0V; T = 0oC to 70oC)
GG
CC
A
Parameter
Symbol
Min
Typ
Max
Units
High Performance Option
Propagation Delay
IN[0:3] to OUT[0:3] (SEL = 1)
CLK to OUT[0:3] (SEL = 0)
SEL to OUT [0:3]
Tpd
Tpd
Tpd
Tpd
200
430
300
250
350
550
430
390
550
780
650
600
ps
ps
ps
ps
EN to OUT [0:3]
Channel to Channel Skew
40
80
ps
1
Maximum Operating Frequency
Fmax
3.0
GHz
1
IN to CLK
Setup Time
Hold Time
Ts
Th
120
120
ps
ps
1
Output rise and Fall Times (20%/80%)
Tr/Tf
125
<1
165
ps
1
o
Temperature Coefficient
ps/ C
∆Tpd/∆T
AC Test Conditions: Outputs terminated with 50Ω to VGG – 2V
Note:
1.
Guaranteed by characterization. Not production tested.
