SK4410
Quad Buffer/Receiver
HIGH-PERFORMANCE PRODUCTS
Description
ꢀeatures
The SK4410 is an extremely fast, stable and accurate
low skew quad buffer or cable driver / receiver. It can
asychronously pass four distinct signals, or it can
resynchronize them to a common clock. In addition, all
four outputs may be asynchronously enabled or
disabled. All of the D flip-flops are triggered on the
rising edge of the CLK input.
•
•
•
•
Quad Buffer/Receiver
3 GHz Fmax
3.3V / 5.2V Compatible
Available in 32 lead, 5mm X5mm, TQFP
Package
Application Notes
The SK4410 has 100Ω input termination resistors
across each of the four inputs to help reduce system
component count and increase integration.
AN1001 - EPIC Family Product Line
AN1003 - Termination Techniques for ECL / LVECL
PECL / LVPECL Devices
AN1004 - Interfacing Between LVDS and ECL /
LVECL / PECL / LVPECL
The SK4410 uses standard open emitter ECL outputs
optimized for:
• Standard, general purpose ECL applications
• Multiple destinations (daisy chain).
Input Options
ꢀunctional Block Diagram
IN
<
0 - 3
>
>
100
IN0
1
IN<
0 - 3
*
OUT0
IN0*
OUT0*
D
Q
0
D* Q*
Output Options
IN1
Open Emitter
1
0
OUT1
OUT1*
IN1*
VCC
D
Q
Q*
D*
IN2
1
0
OUT2
IN2*
OUT2*
OUT
Q
D
Q*
D*
OUT*
IN3
1
0
OUT3
IN3*
OUT3*
Pin Description
D
Q
Q*
D*
CLK
CLK*
SEL*
SEL
EN
EN*
V
CC
VCC
OUT1*
OUT1
SEL
SEL*
V
V
EE
EE
CLK*
CLK
Package Information
OUT2
EN
OUT2*
EN*
V
CC
V
CC
32 pin, 5 mm X 5 mm
TQFP Package
Revision 1/July 10, 2002
