2. Electrical Characteristics
2.1 Absolute Maximum Ratings
Table 2-1: Absolute Maximum Ratings
Parameter
Value
-0.5V to +3.6 VDC
Supply Voltage
Input ESD Voltage
2.5kV
-50°C < Ts < +125°C
Storage Temperature Range
-0.3 to (VCC +0.3)V
Input Voltage Range (any input)
Operating Temperature Range
Solder Reflow Temperature
-40°C to +85°C
260°C
Note: Absolute Maximum Ratings are those values beyond which damage to the device may occur.
Functional operation under these conditions or at any other condition beyond those indicated in the
AC/DC Electrical Characteristic sections is not implied.
2.2 DC Electrical Characteristics
Table 2-2: DC Electrical Characteristics
VCC = 3.3V 5ꢀ or 2.5V 5ꢀ% TA = -40°C to +85°C, unless otherwise shown
Parameter
Symbol Conditions
Min
Typ
Max
Units Notes
3.3V Typical
VCC
3.135
3.3
3.465
V
—
—
1
Supply Voltage
2.5V Typical
2.375
2.5
2.625
V
SDO/SDO enabled
—
135
160
mW
mW
mW
mW
mA
mA
mA
V
Power Consumption
(2.5V)
SDO/SDO disabled
SDO/SDO enabled
SDO/SDO disabled
VCC = 3.3V
—
3
5
1
PD
—
185
222
1
Power Consumption
(3.3V)
—
4
6
1
—
56
64
1
IS
Supply Current
VCC = 2.5V
—
54
61
1
Power-down
—
—
1
1.8
—
1
VCMOUT
VCMIN
V
TERM - VOUT
Output Voltage
Input Voltage
Common mode
—
1.4 + ΔVDDI/2
VCC - ΔVDDI/2
Common mode
—
V
—
