INSTRUCTION SET
S3C4510B
ASSEMBLER SYNTAX
— MRS - transfer PSR contents to a register
MRS{cond} Rd,<psr>
— MSR - transfer register contents to PSR
MSR{cond} <psr>,Rm
— MSR - transfer register contents to PSR flag bits only
MSR{cond} <psrf>,Rm
The most significant four bits of the register contents are written to the N,Z,C & V flags respectively.
— MSR - transfer immediate value to PSR flag bits only
MSR{cond} <psrf>, <#expression>
The expression should symbolise a 32 bit value of which the most significant four bits are written to the N, Z, C
and V flags respectively.
Key:
{cond}
Two-character condition mnemonic. See Table 3-2.
Expressions evaluating to a register number other than R15
CPSR, CPSR_all, SPSR or SPSR_all. (CPSR and CPSR_all are synonyms as are
and SPSR_all)
Rd and Rm
<psr>
SPSR
<psrf>
CPSR_flg or SPSR_flg
<#expression>
Where this is used, the assembler will attempt to generate a shifted immediate 8-bit
field to match the expression. If this is impossible, it will give an error.
Examples
In User mode the instructions behave as follows:
MSR
MSR
MSR
MRS
CPSR_all,Rm
CPSR_flg,Rm
; CPSR[31:28] ¬ Rm[31:28]
; CPSR[31:28] ¬ Rm[31:28]
CPSR_flg,#0xA0000000 ; CPSR[31:28] ¬ 0xA (set N, C; clear Z, V)
Rd,CPSR
; Rd[31:0] ¬ CPSR[31:0]
In privileged modes the instructions behave as follows:
MSR
MSR
MSR
MSR
MSR
MSR
MRS
CPSR_all,Rm
CPSR_flg,Rm
; CPSR[31:0] ¬ Rm[31:0]
; CPSR[31:28] ¬ Rm[31:28]
CPSR_flg,#0x50000000 ; CPSR[31:28] ¬ 0x5 (set Z, V; clear N, C)
SPSR_all,Rm
SPSR_flg,Rm
SPSR_flg,#0xC0000000 ; SPSR_<mode>[31:28] ¬ 0xC (set N, Z; clear C, V)
Rd,SPSR ; Rd[31:0] ¬ SPSR_<mode>[31:0]
; SPSR_<mode>[31:0] ¬ Rm[31:0]
; SPSR_<mode>[31:28] ¬ Rm[31:28]
