S3C4510B
SYSTEM MANAGER
Available Samsung SDRAM Components for S3C4510B
Components
S3C4510B can support below SDRAM configuration for 1 bank.
·
·
·
·
·
2MBytes to 1 bank ® 1 ´ (2Mx32 with 4banks)
4MBytes to 1 bank ® 2 ´ (1Mx16 with 2banks)
8MBytes to 1 bank ® 4 ´ (2Mx8 with 2banks)
16MBytes to 1bank ® 2 ´ (4Mx16 with 2/4banks)
32MBytes to 1bank ® 4 ´ (8Mx8 with 2/4banks)
You can select any combination among them.
SDRAM components that are available are as follow.
x4 SDRAM whose capacity is larger than 16M SDRAM is not supported at S3C4510B.
16M bit SDRAM
— 4Mx4 with 2banks (Supported)
— 2Mx8 with 2banks (Supported)
— 1Mx16 with 2banks (Supported)
RA0–RA10, CA0–CA9
RA0–RA10, CA0–CA8
RA0–RA10, CA0–CA7
64M bit 2Banks SDRAM
— 16Mx4 with 2banks (not supported)
— 8Mx8 with 2banks (supported)
— 4Mx16 with 2banks (supported)
RA0–RA12, CA0–CA9
RA0–RA12, CA0–CA8
RA0–RA12, CA0–CA7
64M bit 4Banks SDRAM
— 16Mx4 with 4banks (not supported)
— 8Mx8 with 4banks (supported)
— 4Mx16 with 4banks (supported)
RA0–RA11, CA0–CA9
RA0–RA11, CA0–CA8
RA0–RA11, CA0–CA7
2Mx32 (64M bit) SDRAM
— 2Mx32 with 4banks (supported)
RA0–RA10, CA0–CA7
100 Pin DIMM Module SDRAM
KMM330S104CT
— 1Mx32 based on 2 1Mx16 2banks components
RA0–RA10, CA0–CA7
RA0–RA10, CA0–CA7
RA0–RA11, CA0–CA7
RA0–RA11, CA0–CA7
KMM330S204CT
— 4Mx32 based on 4 1Mx16 2banks components
KMM330S2424CT
— 4Mx32 based on 2 4Mx16 4banks componets
KMM330S824CT
— 8Mx32 based on 4 4Mx16 4banks componets
