INSTRUCTION SET
S3C4510B
FORMAT 15: MULTIPLE LOAD/STORE
11
10
15
14
13
12
8
7
0
Rlist
1
1
0
0
L
Rb
[7:0] Register List
[10:8] Base Register
[11] Load/Store Bit
0 = Store to memory
1 = Load from memory
Figure 3-44. Format 15
OPERATION
These instructions allow multiple loading and storing of Lo registers. The THUMB assembler syntax is shown in
the following table.
Table 3-22. The Multiple Load/Store Instructions
L
THUMB Assembler
ARM Equivalent
Action
0
STMIA Rb!, { Rlist }
STMIA Rb!, { Rlist }
Store the registers specified by Rlist, starting at the base
address in Rb. Write back the new base address.
1
LDMIA Rb!, { Rlist }
LDMIA Rb!, { Rlist }
Load the registers specified by Rlist, starting at the base
address in Rb. Write back the new base address.
INSTRUCTION CYCLE TIMES
All instructions in this format have an equivalent ARM instruction as shown in Table 3-22. The instruction cycle
times for the THUMB instruction are identical to that of the equivalent ARM instruction.
Examples
STMIA
R0!, {R3-R7}
; Store the contents of registers R3-R7
; starting at the address specified in
; R0, incrementing the addresses for each word.
; Write back the updated value of R0.
3-90
