2.8.11 Start Address3 Register F102h (R/W)
This Read/Write register describes the NAND Flash destination block address which will be copy back programmed.
F102h, default = 0000h
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1
0
Reserved(000000)
FCBA
Device
Number of Block
FBA
512Mb
512
FCBA[8:0]
Start Address3 Information
Register Information
Description
NAND Flash Copy Back Block Address
FCBA
2.8.12 Start Address4 Register F103h (R/W)
This Read/Write register describes the NAND Flash destination page address in a block and the NAND Flash destination sector
address in a page for copy back programming.
F103h, default = 0000h
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1
0
FCSA1)
Reserved(00000000)
FCPA
Start Address4 Information
Item
Description
NAND Flash Copy Back Page Address
NAND Flash Copy Back Sector Address
Default Value
Range
000000 ~ 111111,
6 bits for 64 pages
FCPA
000000
00 ~ 11,
2 bits for 4 sectors
FCSA
00
