Device Operation
PAGE READ
Upon initial device power up, the device defaults to Read mode.This operation is also initiated by writing 00h-30h to the command
register along with five address cycles. In two consecutive read operations, the second one doesn’t need 00h command, which five
address cycles and 30h command initiates that operation. Once the command is latched, it does not need to be written for the follow-
ing page read operation. Two types of operations are available : random read, serial page read .
The random read mode is enabled when the page address is changed. The 2112 bytes(X8 device) or 1056 words(X16 device) of
data within the selected page are transferred to the data registers in less than 25µs(tR). The system controller can detect the comple-
tion of this data transfer(tR) by analyzing the output of R/B pin. Once the data in a page is loaded into the data registers, they may be
read out in 80ns(1.8V device) or 50ns(3.3V device) cycle time by sequentially pulsing RE. The repetitive high to low transitions of the
RE clock make the device output the data starting from the selected column address up to the last column address.
The device may output random data in a page instead of the consecutive sequential data by writing random data output command.
The column address of next data, which is going to be out, may be changed to the address which follows random data output com-
mand. Random data output can be operated multiple times regardless of how many times it is done in a page.
Figure 6. Read Operation
CLE
CE
WE
ALE
tR
R/B
RE
I/Ox
00h
Address(5Cycle)
30h
Data Output(Serial Access)
Col Add1,2 & Row Add1,2,3
Data Field
Spare Field
