ddr2 SdrAM FullY BuFFered ModuleS
Density
Organization
Part Number
Composition
(128M x8)*18
(256M x4)*36
(128M x8)*36
Compliance
Lead free
Lead free
Lead free
Speed (Mbps)
Voltage
1.8V
Rank
Production
Now
2GB
256Mx72
M395T5663FB4-CE68
M395T5160FB4-CE68
M395T5163FB4-CE68
667
667
667
2
2
4
512Mx72
1.8V
Now
4GB
512Mx72
1.8V
Now
Notes:
e6 = PC2-5300 (DDR2-667 @ CL=5)
AMB = IDt L4
Vꢃlꢂagꢀ = 1.8V (AMB Vꢃlꢂagꢀ = 1.5V)
ddr2 SdrAM unBuFFered ModuleS
Density
Organization
Part Number
Composition
(128M x8)*8
(128M x8)*16
Compliance
Lead free
Speed (Mbps)
Rank
Production
Now
1GB
128Mx64
M378T2863FBS-C(E6/F7/E7)
M378T5663FB3-C(E6/F7/E7)
667/800
667/800
1
2
2GB
256Mx64
Lead free
Now
Notes:
e6=PC2-5300 (DDR2-667 @ CL=5)
e7=PC2-6400 (DDR2-800 @ CL=5)
F7=PC2-6400 (DDR2-800 @ CL=6)
Vꢃlꢂagꢀ = 1.8V
ddr2 SdrAM unBuFFered ModuleS (ecc)
Density
Organization
Part Number
Composition
(128Mx8)*9
(128Mx8)*18
Compliance
Lead free
Speed (Mbps)
667/800
Rank
Production
Now
1GB
128Mx72
M391T2863FB3-C(E6/F7)
M391T5663FB3-C(E6/F7)
1
2
2GB
256Mx64
Lead free
667/800
Now
Notes:
e6=PC2-5300 (DDR2-667 @ CL=5)
e7=PC2-6400 (DDR2-800 @ CL=5)
F7=PC2-6400 (DDR2-800 @ CL=6)
Vꢃlꢂagꢀ = 1.8V
ddr2 SdrAM SodiMM ModuleS
Density
Organization
Part Number
Composition
(64Mx16)*8
(128M x8)*8
Compliance
Lead free
Speed (Mbps)
667/800
Rank
Production
Now
1GB
128Mx64
M470T2863FB3-C(E6/F7/E7)
M470T5663FB3-C(E6/F7/E7)
2
2
2GB
256Mx64
Lead free
667/800
Now
Notes:
e6=PC2-5300 (DDR2-667 @ CL=5)
e7=PC2-6400 (DDR2-800 @ CL=5)
F7=PC2-6400 (DDR2-800 @ CL=6)
Vꢃlꢂagꢀ = 1.8V
ddr2 SdrAM coMPonentS
Density
Organization
16Mx16
128M x4
64M x8
Part Number
# Pins-Package Dimensions
Package
Speed (Mbps)
667/800/1066
667/800
Production
256Mb
K4T56163QN-HC(E6/F7/E7/F8)
K4T51043QI-HC(E6/F7/E7)
K4T51083QI-HC(E6/F7/E7/F8)
K4T51163QI-HC(E6/F7/E7/F8)
K4T51043QJ-HC(E6/F7/E7)
K4T51083QJ-HC(E6/F7/E7/F8)
K4T51163QJ-HC(E6/F7/E7/F8)
K4T1G044QF-BC(E6/F7/E7)
K4T1G084QF-BC(E6/F7/E7/F8)
K4T1G164QF-BC(E6/F7/E7/F8)
84-FBGA
60-FBGA
60-FBGA
84-FBGA
60-FBGA
60-FBGA
84-FBGA
68-FBGA
68-FBGA
84-FBGA
7.5x12.5mm
7.5x9.5mm
7.5x9.5mm
7.5x12.5mm
7.5x9.5mm
7.5x9.5mm
7.5x12.5mm
7.5x9.5mm
7.5x9.5mm
7.5x12.5mm
Lead free & Halogen free
Lead free & Halogen free
Lead free & Halogen free
Lead free & Halogen free
Lead free & Halogen free
Lead free & Halogen free
Lead free & Halogen free
Lead free & Halogen free
Lead free & Halogen free
Lead free & Halogen free
Now
Now
Now
Now
Q3
667/800/1066
667/800/1066
667/800
32M x16
128M x4
64M x8
512Mb
667/800/1066
667/800/1066
667/800
Q3
32M x16
256M x4
128M x8
64M x16
Q3
Now
Now
Now
1Gb
667/800/1066
667/800/1066
Notes:
e6=DDR2-667 (5-5-5)
F7=DDR2-800 (6-6-6)
e7=DDR2-800 (5-5-5)
F8=DDR2-1066 (7-7-7)
Vꢃlꢂagꢀ = 1.8V
