Read ID
The device contains a product identification mode, initiated by writing 90h to the command register, followed by an address input of
00h. Four read cycles sequentially output the manufacture code(ECh), and the device code, Reserved(A5h), Multi plane operation
code(C0h) respectively. A5h must be don’t-cared. C0h means that device supports Multi Plane operation. The command register
remains in Read ID mode until further commands are issued to it. Figure 21 shows the operation sequence.
Figure 21. Read ID Operation 1
CLE
tCEA
CE
WE
tAR
ALE
RE
tWHR
tREA
Device
Code
I/O0~7
90h
ECh
00h
A5h
C0h
Maker code
Address. 1cycle
Device code
Multi-Plane code
Device
Device Code
K9F1208Q0A
36h
76h
K9F1208D0A
K9F1208U0A
K9F1216Q0A
K9F1216D0A
K9F1216U0A
76h
XX46h
XX56h
XX56h
