K9F1208Q0A K9F1216Q0A
K9F1208D0A K9F1216D0A
K9F1208U0A K9F1216U0A
FLASH MEMORY
Memory Map
The device is arranged in four 128Mbit memory planes. Each plane contains 1,024 blocks and 528 byte(X8 device) or 264 word(X16
device) page registers. This allows it to perform simultaneous page program and block erase by selecting one page or block from
each plane. The block address map is configured so that multi-plane program/erase operations can be executed for every four
sequential blocks.
Figure 3. Memory Array Map
Plane 3
(1024 Block)
Plane 2
(1024 Block)
Plane 1
(1024 Block)
Plane 0
(1024 Block)
Block 0
Block 2
Block 3
Block 1
Page 0
Page 1
Page 0
Page 1
Page 0
Page 1
Page 0
Page 1
Page 30
Page 31
Page 30
Page 31
Page 30
Page 31
Page 30
Page 31
Block 4
Block 6
Block 7
Block 5
Page 0
Page 1
Page 0
Page 1
Page 0
Page 1
Page 0
Page 1
Page 30
Page 31
Page 30
Page 31
Page 30
Page 31
Page 30
Page 31
Block 4088
Block 4090
Block 4091
Block 4089
Page 0
Page 1
Page 0
Page 1
Page 0
Page 1
Page 0
Page 1
Page 30
Page 31
Page 30
Page 31
Page 30
Page 31
Page 30
Page 31
Block 4092
Block 4094
Block 4095
Block 4093
Page 0
Page 1
Page 0
Page 1
Page 0
Page 1
Page 0
Page 1
Page 30
Page 31
Page 30
Page 31
Page 30
Page 31
Page 30
Page 31
528byte Page Registers
528byte Page Registers
528byte Page Registers
528byte Page Registers
11
