R3112x
ELECTRICAL CHARACTERISTICS
• R3112x091A/C
Topt=25°C
Symbol
−VDET
VHYS
Item
Conditions
Min.
Typ.
Max.
Unit
V
Detector Threshold
0.882 0.900 0.918
0.027 0.045 0.063
Detector Threshold Hysteresis
V
0.6
0.5
2.0
2.0
VDD=0.80V
ISS
Supply Current
μA
VDD=1.90V
VDDH
VDDL
Maximum Operating Voltage
6.0
V
V
0.70
0.80
Topt=25°C
Note1
Minimum Operating Voltage∗
−40°C Topt 85°C
=
=
Nch
10
120
μA
VDS=0.05V, VDD=0.70V
VDS=0.50V, VDD=0.85V
0.05
0.90
mA
IOUT
Output Current (Driver Output Pin)
Pch
1.0
3.5
mA
V
VDS=−2.1V, VDD=4.5V
VTCD
ICD
CD pin Threshold Voltage
CD pin Output Current
0.297 0.495 0.693
VDD=0.99V
2
70
VDS=0.10V, VDD=0.70V
VDS=0.50V, VDD=0.85V
μA
10
400
6.50
RD
Output Delay Resistance
3.25
13.00
MΩ
ppm/
°C
Δ−VDET/
ΔTopt
Detector Threshold
Temperature Coefficient
−40°C Topt 85°C
±100
=
=
RECOMMENDED OPERATING CONDITIONS (ELECTRICAL CHARACTERISTICS)
All of electronic equipment should be designed that the mounted semiconductor devices operate within the
recommended operating conditions. The semiconductor devices cannot operate normally over the
recommended operating conditions, even if when they are used over such conditions by momentary
electronic noise or surge. And the semiconductor devices may receive serious damage when they continue
to operate over the recommended operating conditions.
