T2AB (Transfer data to timer 2 and register R2L from Accumulator and register B)
Instrunction D8
D0
Number of Number of Flag CY
Skip condition
–
words
cycles
code
0
1
0
0
0
1
0
0
0
0
8
8
16
2
1
1
–
Operation:
(R2L7–R2L4) ← (B)
(R2L3–R2L0) ← (A)
(T27–T24) ← (B)
(T23–T20) ← (A)
Grouping:
Timer operation
Description: Transfers the contents of registers A and B
to timer 2 and timer 2 reload register R2L.
T2HAB (Transfer data to register R2H Accumulator from register B)
Number of Number of
Flag CY
–
Skip condition
–
Instrunction D8
D0
words
cycles
code
0
1
0
0
0
1
0
0
1
0
8
5
1
9
3
E
16
16
16
2
1
1
Operation:
(R2H7–R2H4) ← (B)
(R2H3–R2H0) ← (A)
Grouping:
Timer operation
Description: Transfers the contents of register A and
register B to reload register R2H.
T2R2L (Transfer data to timer 2 from register R2L)
Instrunction D8
Number of Flag CY
cycles
D0
Number of
words
Skip condition
–
code
0
0
1
0
1
0
0
1
1
0
2
1
1
–
Operation:
(T27–T24) ← (R2L7–R2L4)
(T23–T20) ← (R2L3–R2L0)
Grouping:
Timer operation
Description: Transfers the contents of reload register
R2L to timer 2.
TAB (Transfer data to Accumulator from register B)
Instrunction D8
D0
Number of Number of Flag CY
Skip condition
–
words
cycles
code
0
0
0
0
1
1
1
1
0
0
2
1
1
–
Operation:
(A) ← (B)
Grouping:
Register to register transfer
Description: Transfers the contents of register B to reg-
ister A.
