NESG3033M14
<R>
EVALUATION CIRCUIT (f = 1.575 GHz LNA)
V
CC
3 V
62 Ω
R3
C4
10 000 pF
5.6 Ω
R2
L2
C3
R1
10 000 pF
3.9 nH
C2
6 pF
82 kΩ
OUT
L1
C1
IN
5.6 nH
10 000 pF
Microstrip
W = 0.15 mm
L = 0.5 mm
× 2
The application circuits and their parameters are for reference only and are not intended for use in actual design-ins.
COMPONENT LIST
<R>
Symbol
Parts
Part Number
GRM155B31H103KA88
GRM1552C1H6R0DZ01
AML1005H5N6STS
AML1005H3N9STS
MCR01MZPJ823
Maker
Murata
Murata
FDK
Value
10 000 pF
6 pF
C1, C3, C4
Chip Capacitor
Chip Capacitor
Chip Inductor
Chip Inductor
Chip Resistor
Chip Resistor
Chip Resistor
C2
L1
L2
R1
R2
R3
5.6 nH
3.9 nH
82 kΩ
5.6 Ω
FDK
ROHM
ROHM
ROHM
MCR01MZPJ5R6
MCR01MZPJ620
62 Ω
R09DS0049EJ0300 Rev.3.00
Sep 14, 2012
Page 12 of 14
