MIL-M-38510/131A
Parameter
symbol
Input pulse signal at
Equation
tr ≤ 50 ns
TR (tr)
+50 mV
TR (tr) = ∆t
TR (os)
+50 mV
TR (os) = 100 (∆V / V )
O
O
NOTES:
1. Resistors are ±1% tolerance and capacitors are 10% tolerance.
2. Precaution should be taken to prevent damage to the D.U.T. suring insertion into socket and in
applying power.
3. R = 604 Ω and C = 22 pF.
L
C
4. Selection circuitry for dual devices is not shown.
5. Device type 01 only.
6. C includes scope, probe, and jig capacitance.
L
FIGURE 4. Test circuit for transient response.
12
