VRS51L1050
VRS51L1050 Program Memory
The VRS51L1050 includes 64KB of on-chip Flash
memory that can be used as program memory or as
general non-volatile data storage memory using the In-
Application Programming (IAP) feature.
When programming the ISP boot program into the
VRS51L1050, the “lock bit” option should be activated
in order to:
o
Protect the ISP Flash memory zone from being
inadvertently erased (this can happen when
the Flash Erase operations are performed
under the control of the ISP boot program),
Prevent the VRS51L1050 Flash from being
read back using a parallel programmer.
ISP Boot Program Memory Zone
The upper portion of the VRS51L1050 Flash memory
can be reserved to store an ISP (In-System
Programmable) boot loader program.
This boot program can be used to program the Flash
memory via the serial interface (or any other method)
with the VRS51L1050’s In-Application Programming
feature. This allows the processor to load the program
from an external device or system and program it into
the Flash memory (see the
VRS51L1050 IAP feature
section).
The size of the memory block reserved for the ISP
boot loader program (when activated) is adjustable
from 512 bytes up to 4KB in increments of 512 bytes.
F
IGURE
3: VRS51L1050-ISP P
ROGRAM SIZE VS
ISP C
ONFIG
. V
ALUE
o
If an erase operation is performed using a parallel
programmer, the entire Flash memory, including the
ISP boot program memory zone, will be erased.
VRS51L1050 ISPV3 Firmware Boot Program
An ISP boot loader program is available for the
VRS51L1050 (ISPVx Firmware, x = revision, see
Ramtron web site for latest revision). The ISPVx
firmware enables In-System-Programming of the
VRS51L1050 on the final application PCB using the
device’s UART interface. See the following figure for a
hardware configuration example (other configurations
are also possible).
F
IGURE
4: VRS51L1050 I
NTERFACE FOR
I
N
-S
YSTEM
P
ROGRAMMING
ISPCFG=1
FFFFh
ISPCFG=2
ISPCFG=3
FE00h
ISPCFG=4
ISPCFG=5
FC00h
ISPCFG=6
ISPCFG=7
FA00h
ISPCFG=8
VRS51L1050
RS232 Transceiver
F600h
F400h
F200h
F000h
To PC
RS232 interf.
ISP Program Size =
ISP Config value x 512Bytes
F800h
(with ISPV3
Firmware)
TXD
RXD
51k
PNP
150k
Creset
RES
0000h
Rreset
Programming the ISP Boot Program
The ISP boot program must be programmed into the
device using a parallel programmer (such as
Ramtron’s VERSAMCU-PPR or a commercial
programmer that supports the VRS51L1050). The
Flash memory reserved for the ISP program is defined
by the parallel programmer software at the moment the
device is programmed.
The VRS51L1050 is available with or without the
ISPVx boot loader firmware (see ordering information
on page 50). The ISPVx boot loader firmware can also
be programmed into the VRS51L1050 by the user.
Source code is included with Ramtron’s Windows™-
based Versa Ware ISP application software, which
allows communication with the ISPVx firmware.
Visit the Ramtron web site to download the Versa
Ware ISP software. For more information on the ISPVx
firmware, consult the “Versa Ware ISP - VRS51L1050
ISPVx User Guide.pdf”, also available on the Ramtron
web site.
