TOP245PN- 参数 Datasheet PDF下载

TOP245PN-图片预览
型号: TOP245PN-
PDF下载: 下载PDF文件 查看货源
内容描述: 的TOPSwitch -GX系列功率扩展,设计灵活, EcoSmart节能,集成离线式开关 [TOPSwitch-GX Family Extended Power, Design Flexible, EcoSmart, Integrated Off-line Switcher]
分类和应用: 开关
文件页数/大小: 52 页 / 2175 K
品牌: POWERINT [ Power Integrations ]
 浏览型号TOP245PN-的Datasheet PDF文件第44页浏览型号TOP245PN-的Datasheet PDF文件第45页浏览型号TOP245PN-的Datasheet PDF文件第46页浏览型号TOP245PN-的Datasheet PDF文件第47页浏览型号TOP245PN-的Datasheet PDF文件第49页浏览型号TOP245PN-的Datasheet PDF文件第50页浏览型号TOP245PN-的Datasheet PDF文件第51页浏览型号TOP245PN-的Datasheet PDF文件第52页
TOP242-250
DIP-8B
D S .004 (.10)
Notes:
.137 (3.48)
MINIMUM
1. Package dimensions conform to JEDEC specification
MS-001-AB (Issue B 7/85) for standard dual-in-line (DIP)
package with .300 inch row spacing.
-E-
2. Controlling dimensions are inches. Millimeter sizes are
shown in parentheses.
3. Dimensions shown do not include mold flash or other
protrusions. Mold flash or protrusions shall not exceed
.006 (.15) on any side.
.240 (6.10)
.260 (6.60)
4. Pin locations start with Pin 1, and continue counter-clock-
wise to Pin 8 when viewed from the top. The notch and/or
dimple are aids in locating Pin 1. Pin 6 is omitted.
5. Minimum metal to metal spacing at the package body for
the omitted lead location is .137 inch (3.48 mm).
6. Lead width measured at package body.
Pin 1
-D-
.367 (9.32)
.387 (9.83)
7. Lead spacing measured with the leads constrained to be
perpendicular to plane T.
.057 (1.45)
.068 (1.73)
(NOTE 6)
.125 (3.18)
.145 (3.68)
.015 (.38)
MINIMUM
-T-
SEATING
PLANE
.008 (.20)
.015 (.38)
.120 (3.05)
.140 (3.56)
.300 (7.62) BSC
(NOTE 7)
.300 (7.62)
.390 (9.91)
.100 (2.54) BSC
.048 (1.22)
.053 (1.35)
T E D S .010 (.25) M
P08B
.014 (.36)
.022 (.56)
PI-2551-121504
SMD-8B
D S .004 (.10)
Notes:
.137 (3.48)
MINIMUM
1. Controlling dimensions are
inches. Millimeter sizes are
shown in parentheses.
-E-
2. Dimensions shown do not
include mold flash or other
protrusions. Mold flash or
protrusions shall not exceed
.006 (.15) on any side.
3. Pin locations start with Pin 1,
and continue counter-clock-
wise to Pin 8 when viewed
from the top. Pin 6 is omitted.
4. Minimum metal to metal
spacing at the package body
for the omitted lead location
is .137 inch (3.48 mm).
.372 (9.45)
.388 (9.86)
.010 (.25)
.240 (6.10)
.260 (6.60)
.420
E S
.046 .060 .060 .046
.080
Pin 1
Pin 1
-D-
.086
.186
.100 (2.54) (BSC)
5. Lead width measured at
package body.
6. D and E are referenced
datums on the package
body.
.286
.367 (9.32)
.387 (9.83)
Solder Pad Dimensions
.057 (1.45)
.068 (1.73)
(NOTE 5)
.125 (3.18)
.145 (3.68)
.004 (.10)
.032 (.81)
.037 (.94)
.048 (1.22)
.053 (1.35)
°
°
.009 (.23)
0 - 8
.036 (0.91)
.044 (1.12)
.004 (.10)
.012 (.30)
G08B
PI-2546-121504
M
48 12/04
