TNY253/254/255
ꢀ
ꢀ
ꢀ
Conditions
Parameter
Symbol
SOURCE = 0 V; TJ = -40 to 125 °C
Max
Units
Min
Typ
See Figure 14
(Unless Otherwise Specified)
OUTPUT (cont.)
DRAIN Supply
Voltage
50
V
TNY253
TNY254
TNY255
14
10
Output Enable
Delay
µs
µs
tEN
Output Disable
Setup Time
tDST
0.5
NOTES:
A. For a threshold with a negative value, negative hysteresis is a decrease in magnitude of the corresponding threshold.
B. Total current consumption is the sum of IS1 and IDSS when ENABLE pin is shorted to ground (MOSFET not switching)
and the sum of IS2 and IDSS when ENABLE pin is open (MOSFET switching).
C. Since the output MOSFET is switching, it is difficult to isolate the switching current from the supply current at the
DRAIN. An alternative is to measure the BYPASS pin current at 6.2 V.
D. BYPASS pin is not intended for sourcing supply current to external circuitry.
E. See typical performance characteristics section for BYPASS pin start-up charging waveform.
F. For current limit at other di/dt values, refer to current limit vs. di/dt curve under typical performance characteristics.
G. This parameter is derived from the change in current limit measured at 5X and 10X of the di/dt shown in the ILIMIT
specification.
470 Ω
5 W
S2
470 Ω
D
S
EN
S
S1
S
S
S
50 V
10 V
BP
0.1 μF
NOTE: This test circuit is not applicable for current limit or output characteristic measurements.
PI-2211-061898
Figure 14. TinySwitch General Test Circuit.
Rev E
02/12
12
