PM73121ꢀAAL1gator II
Data Sheet
PMC-Sierra, Inc.
PMC-980620
,VVXHꢀꢁ
AAL1 SAR Processor
From Version
To Version
Major Changes
Under section 2.8.3 “Peak Cell Rates and Partial Cells”, on
10/17/97
(first version of the
WAC-121-A
01/21/98
•
•
page 22, changed the formula for TCGTOAM.
Under section 3.1.2 “Transmit Signaling Freezing”, on page 32,
added the Dallas Semiconductor part numbers DS2152 and
DS2154.
User’s Manual)
•
•
•
Changed the signal name text in the parentheses in Figure 23 on
page 35.
Added step 8 on page 25, step 9 on page 25, and step 10 on
page 25.
Deleted the NOTE after step 10 on page 36 and added ten more
paragraphs.
•
•
Added section 3.2.1 “Transmit CDV” starting on page 37.
Under section 3.3.2.1 “Header Construction”, on page 39, revised
the fourth sentence.
•
•
Under section 3.4 “Transmit UTOPIA Interface Block
(TUTOPIA)” starting on page 41, added the last two sentences to
the first paragraph on page 43.
Under section 3.6 “Receive Adaptation Layer Processor (RALP)”
starting on page 46, changed the last sentence of the third
paragraph on page 47, added text to the second, sixth, and eight
bullets on page 50.
•
•
•
Under section 3.6.2 “Underrun” starting on page 60, added text to
the third paragraph on page 60.
Under section 3.6.3 “Pointer Processing”, on page 61, added to
text to the third paragraph.
Under section 3.6.4 “Overrun” starting on page 62, added text to
the first and third paragraphs.
•
•
Added step 6 to the NOTES in Figure 47 on page 64.
Under section 3.6.5 “Counters and Sticky Bits”, on page 65,
revised the first paragraph.
•
•
•
Under section 3.7 “Receive Frame Transfer Controller (RFTC)”
starting on page 65.
Under section 3.7.1 “SRTS for the Receive Side” starting on
page 66, revised the first and second paragraphs on page 69.
In the headings of the first columns in Table 3 on page 72 and in
Table 4 on page 72, changed “SRTS_PORT(3:0)” to
“SRTS_LINE(3:0)”.
•
•
Under section 3.8 “Memory Interface and Arbitration Controller
(MIAC)” starting on page 74, added the last sentence to the third
paragraph.
Added section 3.9 “Configuration”, on page 75.
